Fast assembly China Prefabricated Detachable Container Prefab Office Hotel Modular Container House
One-piece living prefabricated Modular house including bathroom toilet kitchen and bedroom
ZCS Container House Specifcation
Folding container house ( 4th Generation)
|
|
|
External dimension (mm)
|
5800 *2500 *2490 / 5830*2438*2400
|
|
Internal dimension (mm)
|
5600*2400*2400
|
|
Folding state (mm)
|
5800*2500*440
|
|
Total mass (kg)
|
1000~1300 Including doors and Windows and simple indoor electrical switch socket [1*40HQ It holds 10 sets]
|
|
|
|
2.3mm galvanized molding beam, zinc content 80g/㎡, 150 wide 5500mm long
|
|
2.3mm galvanized molding beam, galvanized content 80g/㎡, 150 wide 2194mm long
|
|
Galvanized 30*50*1.2mm cross support, galvanized content 80g/㎡
|
|
20*30*1.2mm galvanized square tube, zinc content 80g/square-meter
|
|
20*20*1.0mm galvanized square pipe, galvanized content 80g/㎡
|
|
20-10mm 10mm galvanized square tube, zinc content 80g/square-meter
|
|
0.3mm 831 ceiling tile
|
|
Rolled cotton insulation layer
|
|
Type 50 lifting rail, 5595mm, galvanized content 80g/㎡
|
|
Adapting piece
|
|
|
2.5mm galvanized molding beam, zinc content 80g/㎡, 150 wide 5800mm long
|
|
2.5mm galvanized molding beam, galvanized content 80g/㎡, 150 width 2494mm long
|
|
Lower beam Angle steel flooding, 5800mm
|
|
Lower beam Angle steel flooding, 2494mm
|
|
Galvanized square pipe 40*60*1.7mm galvanized cross support, galvanized content 80g/㎡
|
|
|
2.3mm galvanized column, galvanized content 80g/㎡ 150 wide, 150 wide 2195mm high
|
|
Connector 8.0mm, galvanized content 80g/㎡
|
|
|
3.0mm Upper corner piece, galvanized content 80g/㎡ 150*150*150mm
|
|
3.0mm Lower corner piece, galvanized content 80g/㎡ 150*150*150mm
|
|
|
Skin top 0.4 color steel single shingle, vault, drainage around
|
|
0.47mm color steel single tile, corrugated tile vault, special waterproof method
|
|
Moistureproof
|
Moisture-proof film, PE resin film 1.0mm
|
|
Colour
|
Baking paint (electrostatic spray)
|
|
Bolt
|
Inner hexagon
|
|
|
Downspout
|
50 Downspout
|
|
|
Z type part
|
The 0.8mmZ piece is fixed to the ceiling tile
|
|
|
Cement fibrolite plate
|
16mm thick, 1172*2815mm
|
|
Plastic flooring
|
1.6mm, floor leather
|
|
|
Negative Angle line
|
PVC negative Angle wire
|
|
|
High grade steel door
|
920*2030 steel door (950 wall panel)
|
|
|
Plastic steel window-proof window
|
950*1200 single glass double push (950 type wall panel)
|
Simple electric distribution
|
Simple electric distribution
|
Distribution box J-6 (1), 1 leak protection (32A), 2 five-hole 10A, 2 switches, 1 three-hole 16A, 2 strip cleaning lamps
|
|
|
Model 1150 (Mouth H)
|
50mm rock wool board, double-sided iron sheet 0.3MM bulk weight 50kg/m³
|
|
|
Roof bearing capacity
|
≧50kg/m²
|
|
Aisle bearing capacity
|
≧200kg/m²
|
|
Floor load bearing
|
≧150kg/m²
|
|
Wall side pressure
|
≧80kg/m²
|
|
Wall deformation coefficient
|
≦300kg/m²
|
|
Fire protection level
|
Class A
|
|
Seismic grade
|
Level 10
|
|
Wind resistance rating
|
Level 11
|
ZCS Container House Catalogue
| Model |
Size |
Area |
Structure |
| ZCS Container House-A1 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft
|
17m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
|
| ZCS Container House-A2 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft
|
17m2 |
Living room *1
Bedroom*1 |
| ZCS Container House-A3 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft
|
17m2 |
Living room *1
Bedroom*1
Bathroom*1
Toilet*1 |
| ZCS Container House-A4 |
4m*3m*2.8m/13.12ft*9.84ft*9.18ft |
21.65m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
|
| ZCS Container House-A5 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
68m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
Deck*1 |
| ZCS Container House-A6 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
51m2 |
Living room *1
Bedroom*2
Bathroom*1
Toilet*1
Kitchen*1 |
| ZCS Container House-A7 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
51m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
|
| ZCS Container House-A8 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
68m2 |
Living room *1
Bedroom*3
Kitchen*1
Toilet*2
Bathroom*2 |
| ZCS Container House-A9 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
65m2 |
Living room *1
Bedroom*2
Bathroom*1
Toilet*1
Kitchen*1 |
| ZCS Container House-A10 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
51m2 |
Living room *1
Bedroom*2
Kitchen*1
Toilet*1
Deck*1 |
| ZCS Container House-B1 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
102m2 |
Living room *1
Bedroom*1
Bathroom*1
Toilet*1
Kitchen*1 |
| ZCS Container House-B2 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
68m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
Terrace*1 |
| ZCS Container House-B3 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
68m2 |
Living room *1
Bedroom*3
Toilet*3
Kitchen*1 |
| ZCS Container House-B4 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft
5.95m*1.5m*2.8m /19.52ft*4.92ft*9.18ft |
97.2m2 |
Living room *3
Bedroom*3
Toilet*3
Terrace*1
Kitchen*2 |
| ZCS Container House-B5 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
102m2 |
Living room *2
Bedroom*3
Kitchen*1
Toilet*2
Terrace*1
|
