ZCS Customized cheap and High Quality Steel Structure container house ISO9001 assemble houses
One-piece living prefabricated Modular house including bathroom toilet kitchen and bedroom
ZCS Container House Specifcation
| Specification |
1) 20ft: 5800*2400*2800mm |
| 2)One 40HQ can load 8 units |
| 3) Roof Type: Flat roof with organized internal water draining design |
| 4) Storey: ≤3 |
| Design parameter |
1) Life span: up to 20years |
| 2) Floor Live load: 2.0KN/m2 |
| 3) Roof Live load: 0.5KN/m2 |
| 4) Wind load: 0.6KN/m2 |
| 5) Earthquake-resistance: Grade 8, Fire-proof: Grade 4 |
| Wall panel |
1) Thickness: 75mm fiber glass sandwich panel, effective width: 1150mm |
| 2) Exterior steel sheet (standard configuration): Corrugated 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color: white, Aluminum-zinc thickness≥40g/m2 |
| 3) Insulation layer (standard configuration): 75mm Fiber glass, density≥50kg/m3, Fire-proof standard: grade A non-flambable |
| 4) Interior steel sheet(standard configuration): Flat 0.4mm Aluminum-zinc color steel sheet, PE finishing coat, Color: white, Aluminum-Zinc thickness≥40g/m2 |
| Roof system |
1) Steel frame & accessories: Main roof frame: cold formed steel, thickness=2.5mm, galvanized. with 4pcs galvanized lifting corners. Roof purlin: C80*40*15*2.0, galvanized. Q235B steel |
| 2) Roof panel: 0.4 or 0.5mm thickness Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum thickness≥70g/m2, 360° full connection |
| 3) Insulation: 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3, Grade A fire-proof, nonflammable. |
| 4) Ceiling board: V-170 type, 0.5mm Aluminum-zinc color steel sheet, PE finishing coat. Color: white, Aluminum-zinc thickness≥40g/m2. |
| 5) Industrial socket: Fixed in explosion-proof box at the top beam of the short side, with 1 main power plug for power connection between containers |
| Corner pillar |
1) Cold rolled steel: 4pcs pillar with same dimension, thickness=3mm, steel grade Q235B |
| 2) Corner pillar and main frame are joined by hexagon socket head bolt, strength: grade 8.8. Filled with Fiberglass insulation |
| Floor System |
1) Steel structure & accessories: Main floor frame: cold formed steel, thickness 3.5mm, galvanization; Floor purlin:C120*40*15*2.0, galvanized. Q235B steel. Standard container is Without forklift hole, it can be added according to customer's requirement. |
| 2) Insulation (optional): 100mm thickness Fiber glass with aluminum foil, Density=14kg/m3. Flammability:grade A, nonflammable. |
| 3) Bottom covering (optional): 0.25mm color steel sheet, Zinc thickness≥70g/m2 |
| 4) Floor board: 18mm thickness fiber cement board, Fire-proof:grade B1. Density≥1.3g/cm3 |
| 5) Interior Flooring: 1.5mm thickness PVC leather, Blue marble color |
| Door & Window |
1) Insulated light steel door: Entrance door is W850*H2030mm, Toilet door is W700*H2030mm. |
| 2) PVC sliding window, double glass 5mm thickness, with mosquito screen and security bar. Standard window: W800*H1100mm(for 2.4meter's container), W1130*H1100mm(for 3 meter's container), Toilet window: W800*H500mm |
| Electric system |
1) Rated power: 5.0 KW, suggestion external power source ≤3 in series. |
| 2) Technical parameters: CEE industrial plug, socket voltage 220V- 250V, 2P32A, Fixed in explosion-proof box at the top beam of the short side, the electric cable in the roof is protected by PVC pipe with CE certification; Using IP44 standard power distribution box. |
| 3) Electrical data: main power cable is 6 mm2, AC cable is 4 mm2, socket cable is 2.5 mm2, lighting & switch cable is 1.5 mm2. Five sockets, 1pc AC socket of 3holes 16A, 4pcs socket of 5holes 10A. 1pc single connection switch, 2pcs double tube LED light, 2*15W. |
| Painting |
1) Primer painting: epoxy primer, Zinc color, thickness: 20 - 40 μm. |
| 2) Finishing paint: Polyurethane finishing coat, white color, thickness: 40-50 μm. Total paint film thickness≥80μm. Galvanized components, galvanized layer thickness≥10μm (≥80g/m2) |
ZCS Container House Catalogue
| Model |
Size |
Area |
Structure |
| ZCS Container House-A1 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft
|
17m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
|
| ZCS Container House-A2 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft
|
17m2 |
Living room *1
Bedroom*1 |
| ZCS Container House-A3 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft
|
17m2 |
Living room *1
Bedroom*1
Bathroom*1
Toilet*1 |
| ZCS Container House-A4 |
4m*3m*2.8m/13.12ft*9.84ft*9.18ft |
21.65m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
|
| ZCS Container House-A5 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
68m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
Deck*1 |
| ZCS Container House-A6 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
51m2 |
Living room *1
Bedroom*2
Bathroom*1
Toilet*1
Kitchen*1 |
| ZCS Container House-A7 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
51m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
|
| ZCS Container House-A8 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
68m2 |
Living room *1
Bedroom*3
Kitchen*1
Toilet*2
Bathroom*2 |
| ZCS Container House-A9 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
65m2 |
Living room *1
Bedroom*2
Bathroom*1
Toilet*1
Kitchen*1 |
| ZCS Container House-A10 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
51m2 |
Living room *1
Bedroom*2
Kitchen*1
Toilet*1
Deck*1 |
| ZCS Container House-B1 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
102m2 |
Living room *1
Bedroom*1
Bathroom*1
Toilet*1
Kitchen*1 |
| ZCS Container House-B2 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
68m2 |
Living room *1
Bedroom*1
Kitchen*1
Toilet*1
Terrace*1 |
| ZCS Container House-B3 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
68m2 |
Living room *1
Bedroom*3
Toilet*3
Kitchen*1 |
| ZCS Container House-B4 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft
5.95m*1.5m*2.8m /19.52ft*4.92ft*9.18ft |
97.2m2 |
Living room *3
Bedroom*3
Toilet*3
Terrace*1
Kitchen*2 |
| ZCS Container House-B5 |
5.95m*3m*2.8m /19.52ft*9.84ft*9.18ft |
102m2 |
Living room *2
Bedroom*3
Kitchen*1
Toilet*2
Terrace*1
|
More Products Available
10 X 10 Container House
10x20 Container House
12m Office Containers
2 X 20 Ft Container House
2 X 40 Ft Container House
20ft Flat Pack Container
3 20 Ft Container Home
30ft Container Office
40 Feet Container Office
40ft Flat Pack Containers
4m Flat Pack Container
6m Flat Pack Containers
Container Home 20'
Container Home 20 Feet
Container Home 40ft For Sale
Container Office 10ft
Demountable Container House
Detachable Container Home
Flat Pack Accommodation Units
Flat Pack Container Homes
Luxury Expandable Container House
Modular Expandable Homes
Prefab Flat Pack Home
Flat Pack 1 Bedroom House
2 Bedroom Flat Pack House
3 Bedroom Flat Pack House
4 Bedroom Flat Pack House
5 Bedroom Flat Pack House
2 Story Flat Pack Homes
Double Storey Container Office
Prefabricated Container Office
Modular Prefabricated Container
Prefabricated Container Van
10ft Container Van
20ft Container Van
40 Ft Container Van
40ft Container Van
Prefab Container Van
Modular Container Van
Container Van Assembly
Foldable Container Van
2 Bedroom Prefab Container Homes
3 Bedroom Prefab Container Homes
Foldable 20ft Container
Portable Foldable House
Prefab Fold Out Container Homes
Foldable Mobile Container House
Expandable Folding House
Collapsible Container House
Container Module
Fast Assembly Container House
Modular Container
Prefab Container House
Assemble Container House
About US
Suzhou Zhongchengsheng International Trade Co., Ltd is located in Suzhou City. Our production factory is Suzhou Zhongchengsheng Metal Material Manufacture Co., Ltd. which is a professional enterprise in China's light steel construction industry and a high -tech industrial company integrating R & D, production and sales. Our main products are assembled container house, folding container house, flat pack container house, assemble container house, steel structure house and so on.
We have a perfect supply chain with more than 16 years of experience in raw materials and manufacturing, and can manufacture houses to the satisfaction of our customers according to their customized needs. We are committed to providing first- class quality and efficient pre- sales and after- sales services, and strictly control the quality of our products. Our company has passed the inspection of the national quality inspection department. We have been focusing on providing integrated housing solutions for builders, design institutes, developers and building material dealers.
FAQ
Q1: Are you manufacture factory or trading company ?
A1: We are both manufacture factory and trading company . And you are welcomed to visit us at any time. The quality control flow and sales team will show you.Our factory located in the biggest supplier modular build production based of China--The city is Suzhou of Jiangsu Province.
Q2: What are your main products ?
A2:Our main products have prefab house, Assemble container house, Folding container house, Flat pack container house, sandwich panel and other steel constructive materials.
Q3: Is it difficult to build a prefab house ?
A3: Absolutely not, you can build the house independently according to the construction drawings as long as you know how to use an electric tool.
Q4: What will client provide before factory offers good quotation ?
A4:You tell us container house type, size, quantity, material of roof, wall, floor and other parts, we will check and fast offer you quotation.
Q5: Could you please design a new and unique prefab house for me ?
A5:Absolutely! We are able to provide you with not only construction scheme, but landscape design! One-stop service is our outstanding superiority with no doubt.
